Grizzly Industrial Oscillating Edge Belt and Spindle Sander

About This Product

T27417 Oscillating Edge Belt and Spindle SanderTwo benchtop sanders in one!The T27417 easily converts from an oscillating spindle sander to a 4″ x 24″ oscillating edge belt sander for a limitless variety of sanding applications.Features include a 0-45° tilting table and on-board storage for sanding sleeves, drums, table inserts, and edge sanding attachment.Like all Grizzly sanders, the T27417 comes with a 1-year warranty covering parts and assuring the unit is free from factory defects. (Consumables are not covered by the warranty.)Made in an ISO 9001 factoryCSA certifiedSPECIFICATIONS Motor: 1/2 HP, 120V, single-phase, 3.5A Table size: 16-1/4″ x 16-3/4″ Table tilt: 0-45° Spindle speed: 2000 RPM Spindle stroke: 5/8″ Spindle oscillations: 58 SPM Spindle diameter: 1/2″ Sanding drum length: 4-1/2″ Sanding drum diameters: 3/4″, 1″, 1-1/2″, 2″ Sanding belt speed: 1575 FPM Sanding belt dimensions: 4″ x 24″ Platen dimensions: 4″ x 6-1/8″ Table: Cast aluminum Base: Plastic Dust port size: 1-1/2″ Footprint: 16-1/2″ x 18-1/2″ Overall dimensions: 16-1/2″ W x 18-1/2″ D x 18-1/2″ H Approximate shipping weight: 32 lbs.

Highlights

Combines the advantages of edge belt and spindle sanding all in one tool

Quickly converts from spindle sander to edge belt sander

0-45° tilting table with detents at 0, 15°, 22.5°, 30°, and 45°

Built-in storage for sanding sleeves, sanding drums, table inserts, and edge sanding attachment

Four 4-1/2 in. L sanding drums with table inserts: 3/4 in. 1 in. 1-1/2 in. 2 in. diameter

Five 80-grit sanding sleeves: 1/2 in. 3/4 in. 1 in. 1-1/2 in. 2 in. diameter

1 edge sanding attachment

One 80-grit sanding belt: 4 in. x 24 in.
