JVC GY-HM180 Ultra HD 4K Camcorder with HD-SDI

The JVC GY-HM180 Ultra HD 4K Camcorder with HD-SDI packs multiple pro features into its compact form, with updates including a 3G-SDI output in addition to an HDMI out. Its single 1/2.3″ 12.4MP CMOS sensor captures UHD 4K images in 24 or 30p, at bit rates of 150 or 70 Mb/s, Full HD up to 60p/50 Mb/s, and HD up to 120 fps for smooth slow motion. The 3G-SDI and HDMI outputs can be used to feed and trigger an external recorder.

Lower-res proxy files may be recorded simultaneously with full-size HD files, providing smaller files suitable for posting to the web or editing on the go. Live UHD 4K is output via the HDMI port, with HD video supported via the 3G-SDI BNC port. GY-HM180 viewing options include a 3.5″ LCD screen, a 0.24 color viewfinder, and a smart focus-assist function.

Additional features include hot-swappable dual SDHC/SDXC card slots, two internal ND filters, and a histogram display. Pro-style audio features include 2-channel XLR audio inputs and a built-in stereo mic. Capture options include recording 1080p up to 60 fps in a 4:2:2, 50 Mb/s .MOV file, or in AVCHD for compatibility with a variety of HD/SD formats and editing systems. The JVC GY-HM180 comes with a top handle unit, a hood, and an AC adapter with a power cord.

User Manual

10.9 MB

Key Features

Pro-style audio features include XLR audio inputs with phantom power for external mics, as well as a built-in stereo mic

• Record UHD 4K at 150 Mb/s to UHS-I Class 3 or faster SDXC cards, or at 70 Mb/s to Class 10 or higher SDXC/SDHC cards
• Output live 4K via HDMI for monitoring, 4K switcher use, or external recording; output HD using the 3G-SDI BNC connector
• Capture 4:2:2 HD images in MOV-wrapped 50 Mb/s files, or in 4:2:0 AVCHD files for compatibility with a variety of HD/SD formats and editing systems
• Two SDHC/SDXC memory card slots enable simultaneous recording to provide a backup or relay recording with hot-swapping for uninterrupted shooting
• Record lower-resolution proxy files at the same time as full-size HD; these smaller files are perfectly suited for posting to the web, or for quick editing
• A 3.5″ color LCD panel features a 920,000-pixel resolution, while the 0.24″ viewfinder offers a crisp 1.56 million-pixel resolution
• The 12x optical / 24x digital zoom uses pixel mapping in HD mode for seamless extended zooming
• Use the two-position ND filter (1/4 and 1/16) for adjustable image control, including the use of a slower shutter speed for more natural motion blur
• Pro-style audio features include XLR audio inputs with phantom power for external mics, as well as a built-in stereo mic
